Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 45
Parameter Descriptions Chapter 2
The following table illustrates the relationship:
When you display a specific bit-encoded parameter, or choose to modify a bit-
encoded parameter, it will be displayed in bit format, with an individual
description of each bit. When modifying a parameter, highlighting the bit with
the cursor keys will automatically pop up the description on screen.
Conversion Table
Bit 15 14 131211109876543210
Value
8 421842184218421
Example
0 101111010110011
0 + 4 + 0 + 1 8 + 4 + 2 + 0 8 + 0 + 2 + 1 0 + 0 + 2 + 1
Sums
5EB3
Binary Hex Binary Hex Binary Hex Binary Hex
0000 0 0100 4 1000 8 1100 C
0001 1 0101 5 1001 9 1101 D
0010 2 0110 6 1010 A 1110 E
0011 3 0111 7 1011 B 1111 F
