Rockwell Automation Publication 6000-TD004D-EN-P - November 2017 47
Parameter Descriptions Chapter 2
Owner #3 Selection
Linear Number: P477
Default Value: 23
Minimum Value: 18
Maximum Value: 23
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Online/Offline
This parameter is used to select the Frequency Reference source and Control
Command source when the drive control mode is set to Remote Box (mainly
refers to the Start command).
Local/Remote Owner Selection
Linear Number: P478
Default Value: 0
Minimum Value: 0
Maximum Value: 3
Access Level: Setup, R&D
Read/Write: Read/Write
Modify Level: Offline only
This parameter is used to set the location to switch the drive control mode
between Local, DCS, and Remote box.
Table 8 - Frequency Reference and Control Command Source Matrix for Parameter P477
Frequency Owner
Control Owner
HMI Comm /
Local Button
DCS I/O DCS Comm Remote Box
(Option)
HMI N/A N/A N/A 18
Potentiometer
0-10V (Option)
N/A N/A N/A 19
Analog 4-20 mA N/A N/A N/A 20
Comm N/A N/A N/A 21
4-Speed N/A N/A N/A 22
Remote Box N/A N/A N/A 23
Value Description
0 Selection is done on the HMI.
1 Selection is done using a switch mounted on the control panel.
2 Selection is done on the HMI and a switch mounted on the user site.
3 Selection is done using a switch mounted on the control panel and a switch on the user site.
