12.3.8 E8
13
Replace the main card and try to run a
program again except spinning or
pump.
PICTURE E8-2: KN1-KN1D-KN8 connectors on the card
PICTURE E8-1: AC voltage is being measured over valve connectors
Is there E8 error?
*Program lasts long.
* The machine does not end the
programme
*Machine is not taking in water
*Machine does not work.
*It does not spin and drain
*THE MACHINE CONTINUOUSLY
DISCHARGES.
Yes
Y
ES
Is the machine taking in water?
No
Yes
Check taps and filters and see if they are open or
not. Is the tap turned off or the filter clogged?
*Is the machine continuously pumping and
discharging water although it is taking in
water?
*Water cut off or
*Valve triac open or
*Pump triac short
circuit error
Yes
No
Turn the taps on and try
again.
INFORMATION:
FOR KN13
M
AIN WASH PIN 1-3 BLUE
P
REWASH PIN 4-6 RED
No
Yes
No
No
Yes
Make sure that the valve connectors (picture E8-1) and
control card KN13-KN-16 (picture E8-2) are fitted. Are
connectors fitted?
Attach the connectors
and try again.
PICTURE E8-3 AC voltage is being measured over valve connectors
Is there 220VAC between the connectors of
the valve that has to operate? (Picture E8-1)
Replace the valve. Try
again.
Y
ES
YES
Is there 220 VAC between KN13 connector pin
1 and pin 3. on the control card?
(Picture E8-3)
Replace the control card
and try again.
Important Note:
Prewash and main wash valves are activated concurrently
in the softener step. Thus, water is sent to softener
compartment.
Is there any error on the cable connections
between the control card and the water inlet
valves?
Correct connections and
check. Try again
