B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
111
12.3.11 E11_1
*Motor phase
open circuit
E11
* Program
remains
incomplete.
* The machine
makes sudden
start ups.
* Machine
drum does not
rotate at all.
Is there E11 error?
Replace the motor
(Picture E11-1)
Yes
Try to start a program again.
NOTE: Speed control card of the BLAC motor used
in this product is located on the motor itself. In
cases conforming to E11 error definition, motor
must be replaced.
Picture E11-1: BLAC Motor
Are the cables between
the control card and the
motor sturdy?
Is the motor impedance coil
sturdy? (Impedance coil windings
should not be broken)
Yes
Yes
Picture E11_1 : Impedance coil
To Next Page
