B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
86
Picture 9.23 Jet system pump
When resistance is read from pump tips with multimeter, a value between 155 and 180W
should be read.
9.16. Aquastop (Overflow key)
Due to the water leakages that may occur in the machine, it is used for safety purposes.
If water comes on to the lower closure plate in the machine, it cuts the water coming to the
machine with the help of key connected to the card to prevent likely overflows and safety
violations.
Picture 9.24 Aquastop
Nominal Voltage : 220-240 V 50Hz
Resistance : 160 ohm
