arcelik Beko B13 - Steam Generator Water Hose Attachment; Detachment; Picture 15.72; Picture 15.73; Picture 15.74

B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
159
Picture 15.72
Picture 15.73
15.9.4. Steam Generator Water Hose Attachment / Detachment
Detachment
 Steam generator must be removed. See, 15.8.1.
 Upper table must be removed. See, 15.1.2.
Picture 15.74
Bracket on the steam hose end
at the drum side will be
attached by needle pliers.
You must make sure that the
hoses are properly fitted.
Hoses should not touch each
other. Steam hose should not
touch the drum and rear wall.
Bracket of the generator
water hose shown below
(end at the detergent box
connection hoses side) is
removed and the hose is
taken out.
