arcelik Beko B13 - Drain Pump Attachment; Detachment

B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
169
15.20. Lower Balance Weight Attachment / Detachment
Front wall is removed.
Lower Balance Weight is taken by removing the Fitting Bolts. (While performing upper
and lower balance attachment, torque value must be 1900 Ncm (with -200 tolerance).)
Picture 15.102 Lower balance weight
15.21. Drain Pump Attachment / Detachment
 Upper table is removed.
 Panel is removed.
 Front wall is removed.
 Screws on the body are removed.
 Drain hose is drawn back to the bracket at the Pump inlet.
 Pump is taken out.
Picture 15.103 Drain pump
