arcelik Beko B13 - Picture 15.87 Step 3; Picture 15.88 Step 4; Picture 15.89 Step 5

B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
164
Picture 15.87 Step 3
Picture 15.88 Step 4
Picture 15.89 Step 5
Step-5: Input
impedance coil is
controlled visually
Step 3. Impedance coil is
turned 90 degrees
clockwise to ensure that
the cam engages into
the hole securely.
Step 4. It is installed
onto the body by
tightening the 4*10mm
1.1 screws from
outside.
