arcelik Beko B13 - It Takes Water in from the Wrong Compartment

B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
124
Takes in water from the wrong detergent
compartment
Correct connections. Check by
performing a function test.
Yes
No
Make a function test for the machine to
check the compartments of the detergent
box.
During the test steps check if there is 220
VAC on the related valve
Yes
No
Are the valves connected to
KN1 - Prewash (blue)
KN1 - Main wash (red)
KN8 – Steam (yellow)
KN10 - Hot water (pink)
(Picture-1)
ends?
Is there 220VAC voltage on the relevant
valve during water intake from each
compartment?
Replace the valve
Replace the control card
Main wash valve
Hot water valve
Picture E17-1 : Valves and drawer hose connection
Steam generator valve
Prewash valve
Main wash valve
Hot water valve
12.3.21 It takes water in from the wrong compartment
