arcelik Beko B13 - Steam Generator Does Not Function

B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
126
12.3.23 Steam generator does not function
Picture-1_1 : Steam generator KN23 input
socket
Steam generator does not function
Are steam generator resistance values
correct?
Yes
Is the steam generator KN23 input
socket control card attached? (Picture-
1_1 )
Yes
Picture-1_2 : Steam generator KN23 input
socket is being measured
Picture-1_3 : Steam generator is being
measured via other connection socket
Perform resistance measurement
over control card over KN23
(Picture-1_2 ) socket and over
steam generator's other steam
generator (Picture-1_3 ) . It is
measured as approx. 47 ohm.
Replace the steam
generator (Picture-1_4)
No
Replace the control card
Picture-1_4 : Steam generator
KN23
