B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
123
Remove heater sockets to check
if there is short to the heater.
Does the machine cause
continuous fuse blow out and
isn't there an error code?
Is the heater short
circuited?
Replace the heater.
Yes
Check the cabling of the
machine; is there any stripped,
broken or burnt cable?
No
Correct the cabling.
Yes
Is there any trace of
burning or burst on
the control card?
Operate the machine
one more time; does
it run for a while
without blowing the
fuse?
check in a function test to see
which part is causing fuse blow.
Remove the socket ends of the
part blowing the fuse and perform
a short circuit control. Replace
the part if there is short circuit. If
not, check the cabling again.
Make sure that no water is
coming onto the control card,
motor, heater, pump, door lock
or valves of the machine.
Replace the control card
No
Yes
Yes
Does the machine
persist blowing the
fuse?
No
Yes
Yes
12.3.20 Machine is Blowing the Fuse
To Next Page
