B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
138
15.2.2. Detachment
Before detaching the panel assembly, uppr table assembly has to be detached.
Picture 15.12 Panel detachment -1
Picture 15.13 Panel detachment 2
Picture 15.14
Picture 15.1 Panel detachment 4
Detergent drawer is taken out
by pressing on the siphon part
as shown in Picture 15.12.
3 screws shown in Picture
15.14 are removed.
Cable string connecting the
cable group to the card holder
is cut as shown in Picture
15.15.
