arcelik Beko B13 - MOTOR

B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
165
15.15. MOTOR
15.15.1. BLAC External rotor motor
15.1.1.1. Askoll motor
 Rear wall is removed. Poly-V belt is taken out.
 Motor-Drum connection screws are removed (2 pieces).
 Motor is connected to the drum at three points; 2 in the front and 1 at the back.
 power and communication connections are removed.
 Check that the rear connection and the rubber gasket on it seat well during mounting.
Picture 15.90 Motor
15.15.1.2.Atlas motor
Picture 15.91 Motor
 Rear wall is removed. Poly-V belt is taken out.
 Motor-Drum connection screws are removed (2 pieces).
 Motor is connected to the drum at three points; 2 in the front and 1 at the back.
 power and communication connections are removed.
 Check that the rear connection and the rubber gasket on it seat well during mounting.
