B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
16
Figure 5.6
3 When hose connection is completed, check whether there is leak problems at the
connection points by opening the taps fully. If any leaks occur, turn off the tap and remove
the nut. Retighten the nut carefully after checking the seal. In order to prevent the water
leaks and resultant damages, keep the taps closed when you do not use the product.
5.5. Connecting to water drain
The end of the drain hose must be directly connected to the wastewater drain or to the
washbasin.
WARNING:
Your house will be flooded if the hose comes out of its housing during water
discharge. Moreover, there is risk of scalding due to high washing temperatures! To prevent such
situations and to ensure smooth water intake and discharge of the machine, fix the end of the
discharge hose tightly so that it cannot come out.
The hose should be attached to a height of at least 40 cm, and 100 cm at most.
Figure 5.7
In case the hose is elevated after laying it on the floor level or close to the ground (less than 40
cm above the ground), water discharge becomes more difficult and the laundry may come out
excessively wet. Therefore, follow the heights described in the figure.
To prevent flowing of dirty water back into the machine and to allow for easy discharge, do not
immerse the hose end into the dirty water or do not drive it in the drain more than 15 cm. If it is
too long, cut it short.
The end of the hose should not be bent, it should not be stepped on and the hose must not be
pinched between the drain and the machine.
2. Tighten all hose nuts by
hand. Never use a tool
when tightening the nuts.
