B13 BETTER (B13 BEST APPEARANCE) WASHING MACHINE SERVICE HANDBOOK
154
Picture 15.59
Picture 15.60
Rear cover must be attached and screws must be tightened.
Picture 15.61
15.9.2. Steam Generator Bracket Attachment / Detachment
Two screws holding the steam
generator must be tightened.
You must make sure that the
hoses are properly fitted.
Hoses should not touch each
other. Steam hose should not
touch the drum and rear wall.
To Next Page
