Bus Interface Unit
6-4 Copyright © 2001-2003 ARM Limited. All rights reserved. ARM DDI0198D
Table 6-1 shows the HBURST encodings that the ARM926EJ-S processor uses, and the
operations that perform each burst size.
Note
Incr4 and Incr8 bursts can be aligned to any word boundary.
The ARM926EJ-S processor performs all Thumb instruction fetches as word-wide
transfers on the AHB. See Mapping of level one and level two (AHB) attributes on
page 6-5.
All burst reads and writes are performed by the ARM926EJ-S processor as word-wide
transfers (HSIZE[2:0] = 010). Single reads and writes are performed as byte
(HSIZE[2:0] = 000), halfword (HSIZE[2:0] = 001), or word wide transfers
(HSIZE[2:0] = 010).
Table 6-1 Supported HBURST encodings
HBURST[2:0] Description Operation
Single Single transfer Single transfer of word, halfword, or byte:
• data write (NCNB, NCB, WT, or WB that has missed in DCache)
• data read (NCNB or NCB)
• NC instruction fetch (prefetched and non-prefetched)
• page table walk read
• continuation of a burst that either lost grant or received a
Split/Retry response.
Incr4 Four-word incrementing
burst
Half-line cache write-back. Instruction prefetch, if enabled. Four-word
burst NCNB, NCB, WT, or WB write.
Incr8 Eight-word incrementing
burst
Full line cache write-back. Eight-word burst NCNB, NCB, WT, or WB
write.
Wrap8 Eight-word wrapping burst Cache linefill.
