CP15 Test and Debug Registers

Table B-12 describes the bit fields of the Memory Region Remap Register.

Table B-13 shows the encoding of each of the remap fields.

Table B-12 Encoding of the Memory Region Remap Register

Bit Name Definition Reset state

[31:16] - Should Be Zero

0x0000

[15:14] IWB Remap select bits for instruction-side write-back region b11

[13:12] IWT Remap select bits for instruction-side write-through region b10

[11:10] INCB Remap select bits for instruction-side noncachable bufferable region b01

[9:8] INCNB Remap select bits for instruction-side noncachable nonbufferable region b00

[7:6] DWB Remap select bits for data-side write-back region b11

[5:4] DWT Remap select bits for data-side write-through region b10

[3:2] DNCB Remap select bits for data-side noncachable bufferable region b01

[1:0] DNCNB Remap select bits for data-side noncachable nonbufferable region b00

Table B-13 Encoding of the remap fields

Remap field

b00 = noncachable nonbufferable

b01 = noncachable bufferable

b10 = write-through

b11 = write-back
