Programmer’s Model
ARM DDI0198D Copyright © 2001-2003 ARM Limited. All rights reserved. 2-9
Figure 2-2 Cache Type Register format
Ctype The Ctype field determines the cache type. See Table 2-6.
S bit Specifies if the cache is a unified cache (S=0), or separate ICache and
DCache (S=1). If S=0, the Isize and Dsize fields both describe the unified
cache and must be identical. In the ARM926EJ-S processor, this bit is set
to a 1 to denote separate caches.
Dsize Specifies the size, line length, and associativity of the DCache, or of the
unified cache if the S bit is 0.
Isize Specifies the size, length, and associativity of the ICache, or of the
unified cache if the S bit is 0.
The Ctype field specifies if the cache supports lockdown or not, and how it is cleaned.
The encoding is shown in Table 2-6. All unused values are reserved.
The Dsize and Isize fields in the Cache Type Register have the same format. This is
shown in Figure 2-3.
Figure 2-3 Dsize and Isize field format
Size The Size field determines the cache size in conjunction with the M bit.
0
31 30 29 28 25 24 23 12 11 0
0 0 Ctype S Dsize Isize
Table 2-6 Ctype encoding
Value Method Cache cleaning Cache lockdown
b1110 Write-back Register 7 operations
Format C
a
a. See Cache Lockdown Register c9 on page 2-26 for more details on
Format C for cache lockdown.
11 10 9 6 5 3 2 1 0
0 0 Size Assoc M Len
