ARM ARM926EJ-S User Manual

Programmer’s Model
ARM DDI0198D Copyright © 2001-2003 ARM Limited. All rights reserved. 2-3
2.2 Summary of ARM926EJ-S system control coprocessor (CP15) registers
CP15 defines 16 registers. Table 2-1 shows the read and write functions of the registers.
Table 2-1 CP15 register summary
Register Reads Writes
0
ID code
a
a. Register locations 0, 5, and 13 each provide access to more than one register. The register
accessed depends on the value of the
Opcode_2 field.
Unpredictable
0
Cache type
a
Unpredictable
0
TCM status
a
Unpredictable
1 Control Control
2 Translation table base Translation table base
3 Domain access control Domain access control
4 Reserved Reserved
5
Data fault status
a
Data fault status
a
5
Instruction fault status
a
Instruction fault status
a
6 Fault address Fault address
7 Cache operations Cache operations
8 Unpredictable TLB operations
9
Cache lockdown
b
b. Register location 9 provides access to more than one register. The register accessed depends
on the value of the
CRm field. See the register descriptions for details.
Cache lockdown
9 TCM region TCM region
10 TLB lockdown TLB lockdown
11 and 12 Reserved Reserved
13
FCSE PID
a
FCSE PID
a
13
Context ID
a
Context ID
a
14 Reserved Reserved
15 Test configuration Test configuration
