Programmer’s Model
ARM DDI0198D Copyright © 2001-2003 ARM Limited. All rights reserved. 2-23
The MVA format for Rd for the CP15 c7 MCR operations is shown in Figure 2-9. The
Tag, Set, and Word fields define the MVA. For all of the cache operations, Word Should
Be Zero.
Figure 2-9 Register c7 MVA format
The Set/Way format for Rd for the CP15 c7 MCR operations is shown in Figure 2-10
on page 2-24, where A and S are the base-two logarithms of the associativity and the
number of sets. The Set, Way, and Word fields define the format. For all of the cache
operations, Word Should Be Zero.
For a 16KB cache, 4-way set associative, 8-word line, then:
• A = log
2
associativity = log
2
4 = 2
• S = log
2
NSETS where:
NSETS= cache size in bytes/associativity/line length in bytes:
NSETS= 16384/4/32 = 128
Therefore:
S = log
2
128 = 7
Invalidate DCache single entry (Set/Way) Set/Way MCR p15, 0, <Rd>, c7, c6, 2
Clean DCache single entry (MVA) MVA MCR p15, 0, <Rd>, c7, c10, 1
Clean DCache single entry (Set/Way) Set/Way MCR p15, 0, <Rd>, c7, c10, 2
Test and clean DCache - MRC p15, 0, <Rd>, c7, c10, 3
Clean and invalidate DCache entry (MVA) MVA MCR p15, 0, <Rd>, c7, c14, 1
Clean and invalidate DCache entry (Set/Way) Set/Way MCR p15, 0, <Rd>, c7, c14, 2
Test, clean, and invalidate DCache - MRC p15, 0, <Rd>, c7, c14, 3
Drain write buffer SBZ MCR p15, 0, <Rd>, c7, c10, 4
Wait for interrupt SBZ MCR p15, 0, <Rd>, c7, c0, 4
Table 2-18 Cache operations c7 (continued)
Function/operation Data format Instruction
Tag
31 S+5 S+4 5 4 2 1 0
Set (= index) Word SBZ
