CHAPTER58 Viewing VoIP Status
Mediant 800 Gateway & E-SBC | User's Manual
Column Name Description
■ Destination IP address as configured in the Tel-to-IP Routing table.
■ Destination IP address resolved from the host name (FQDN) as
configured in the Tel-to-IP Routing table.
Host Name Displays the host name (or IP address) as configured in the Tel-to-IP
Routing table.
Connectivity
Method
Displays the method according to which the destination IP address is
queried periodically by the device to check keep-alive connectivity
status (SIP OPTIONS request). To configure the keep-alive
mechanism, see IP Destinations Connectivity Feature.
Connectivity
Status
Displays the connectivity status with the destination:
■ "OK": Remote side responds to periodic connectivity queries.
■ "Lost": Remote side didn't respond for a short period.
■ "Fail": Remote side doesn't respond.
■ "Init": Connectivity queries not started (e.g., IP address not
resolved).
■ "Disable": The connectivity option is disabled, i.e., parameter 'Alt
Routing Tel to IP Mode' (AltRoutingTel2IPMode ini) is set to None
or QoS. For more information, see Alternative Routing Based on IP
Connectivity.
Quality Status Displays the QoS (according to packet loss and delay) of the
destination:
■ "Unknown": Recent quality information isn't available.
■ "OK"
■ "Poor"
Note:
■ The parameter is applicable only if the parameter 'Alt Routing Tel to
IP Mode' is set to QoS or Both (AltRoutingTel2IPMode = 2 or 3).
■ The parameter is reset if two minutes elapse without a call to the
destination.
Quality Info Displays QoS information: delay and packet loss, calculated according
to previous calls.
Note:
■ The parameter is applicable only if the parameter 'Alt Routing Tel to
IP Mode' is set to 'QoS' or 'Both' (AltRoutingTel2IPMode = 2 or 3).
■ The parameter is reset if two minutes elapse without a call to the
destination.
DNS Status DNS status:
■ "DNS Disable"
■ "DNS Resolved"
■ "DNS Unresolved"
- 1018 -
