CHAPTER72 Configuration Parameters Reference
Mediant 800 Gateway & E-SBC | User's Manual
Parameter Description
'SBC RTCP XR Report Mode'
configure voip > sip-
definition settings > sbc-
rtcpxr-report-mode
[SBCRtcpXrReportMode]
Enables the sending of RTCP XR reports of QoE
metrics at the end of each call session (i.e., after a
SIP BYE). The RTCP XR is sent in the SIP
PUBLISH message.
■ [0] Disable (default)
■ [1] End of Call
Note: The parameter is applicable only to the SBC
application.
Gateway Application Parameters
this section describes the parameters of the Gateway application.
Fax and Modem Parameters
The fax and modem parameters are described in the table below.
Table 72-37:Fax and Modem Parameters
Parameter Description
'Fax Transport Mode'
configure voip > media fax-modem >
fax-transport-mode
[FaxTransportMode]
Determines the fax transport mode used
by the device.
■ [0] Disable = transparent mode
■ [1] T.38 Relay (default)
■ [2] Bypass
■ [3] Events Only
Note: The parameter is overridden by the
parameter [IsFaxUsed]. If the parameter
[IsFaxUsed] is set to 1 (T.38 Relay) or 3
(Fax Fallback), then [FaxTransportMode]
is always set to 1 (T.38 relay).
V34-fax-transport-type
[V34FaxTransportType]
Determines the V.34 fax transport
method (whether V34 fax falls back to
T.30 or pass over Bypass).
■ [0] = Transparent
■ [1] = (Default) Relay
■ [2] = Bypass
■ [3] = Transparent with Events
Note: To configure
[V34FaxTransportType] to [1] (i.e., fax
relay), you also need to configure
[FaxTransportMode] to [1] (fax relay).
'V.21 Modem Transport Type'
configure voip > media fax-modem >
V21-modem-transport-type
[V21ModemTransportType]
Determines the V.21 modem transport
type.
■ [0] Disable = (Default) Transparent.
■ [2] Enable Bypass
- 1279 -
