CHAPTER69 Testing SIP Signaling Calls
Mediant 800 Gateway & E-SBC | User's Manual
➢ To configure played DTMF signal to answered test call:
1. Open the Test Call Settings page (Troubleshoot menu > Troubleshoot tab > Test Call folder
> Test Call Settings).
2. In the 'Test Call DTMF String' field, enter the DTMF string (up to 15 digits):
3. Click Apply.
Configuring Basic Test Calls
The Basic Test Call feature tests incoming calls from remote SIP (IP) endpoints to a single
simulated test endpoint on the device. The only required configuration is to assign a prefix number
(test call ID) to the simulated endpoint. Incoming calls with this called (destination) prefix number
are identified by the device as test calls and sent to the simulated endpoint. The figure below
displays a basic test call example:
➢ To configure basic call testing:
1. Open the Test Call Settings page (Troubleshoot menu > Troubleshoot tab > Test Call folder
> Test Call Settings).
2. In the 'Test Call ID' field, enter a prefix for the simulated endpoint:
For a full description of the parameter, see SIP Test Call Parameters.
3. Click Apply.
● The device can play DTMF tones to the remote endpoint. For more information, see
Configuring DTMF Tones for Test Calls.
● The Basic Test Call feature uses the default IP Group (ID #0) and its associated IP
Profile (if exists).
● Test calls are done on all SIP Interfaces.
Test Call Configuration Examples
Below are a few examples of test call configurations.
■ Single Test Call Scenario: This example describes the configuration of a simple test call
scenario that includes a single test call between a simulated test endpoint on the device and a
remote endpoint.
- 1142 -
