CHAPTER72 Configuration Parameters Reference
Mediant 800 Gateway & E-SBC | User's Manual
Parameter Description
■ [3] RFC 4733 Along with RTP
VBD = The device transfers the CED
tone in RFC 2833 and bypass, in
parallel. For combined V.150.1
modem relay and fax relay, use this
option.
V.150.1 Modem over IP
'Profile Number'
[V1501AllocationProfile]
Defines the V.150.1 profile, which
determines how many DSP channels
support V.150.1.
The value range is 0 to 20. The default is
0.
Note: For the parameter to take effect, a
device reset is required.
'SSE Payload Type Rx'
configure voip > media fax-modem >
V1501-SSE-payload-type-rx
[V1501SSEPayloadTypeRx]
Defines the V.150.1 (modem relay
protocol) State Signaling Event (SSE)
payload type Rx.
The value range is 96 to 127. The default
is 105.
'SSE Redundancy Depth'
configure voip > media fax-modem >
SSE-redundancy-depth
[V1501SSERedundancyDepth]
Defines the SSE redundancy depth.
The value range is 1-6. The default is 3.
'SPRT Transport Ch.0 Max Payload Size'
configure voip > media fax-modem >
SPRT-transport-channel0-max-payload-
size
[V1501SPRTTransportChannel0MaxPayloadSize]
Defines the maximum payload size for
V.150.1 SPRT Transport Channel 0.
The range is 140 to 256. The default is
140.
'SPRT Transport Ch.2 Max Payload Size'
configure voip > media fax-modem >
SPRT-transport-channel2-max-payload-
size
[V1501SPRTTransportChannel2MaxPayloadSize]
Defines the maximum payload size for
V.150.1 SPRT Transport Channel 2.
The range is 132 to 256. The default is
132.
'SPRT Transport Ch.2 Max Window Size'
configure voip > media fax-modem >
SPRT-transport-channel2-max-window-
size
[V1501SPRTTransportChannel2MaxWindowSize]
Defines the maximum window size of
SPRT transport channel 2.
The value range is 8 to 32. The default is
8.
'SPRT Transport Ch.3 Max Payload Size' Defines the maximum payload size for
V.150.1 SPRT Transport Channel 3.
