CHAPTER16 Services
Mediant 800 Gateway & E-SBC | User's Manual
The device provides a preconfigured LDAP Server Group
("DefaultCTRLServersGroupin") in the LDAP Server Groups table, which can be
modified or deleted.
➢ To configure an LDAP Server Group:
1. Open the LDAP Server Groups table (Setup menu > IP Network tab > RADIUS & LDAP
folder > LDAP Server Groups).
2. Click New; the following dialog box appears:
3. Configure an LDAP Server Group according to the parameters described in the table below.
4. Click Apply.
Table 16-8: LDAP Server Groups Table Parameter Descriptions
Parameter Description
General
'Index'
[LdapServerGroups_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Name'
name
[LdapServerGroups_Name]
Defines a descriptive name, which is used when associating
the row in other tables.
The valid value is a string of up to 20 characters.
Note:
■ Each row must be configured with a unique name.
■ The parameter value cannot contain a forward slash (/).
'Type'
server-type
[LdapServerGroups_
ServerType]
Defines whether the servers in the group are used for SIP-
related LDAP queries (Control) or management login
authentication-related LDAP queries (Management).
■ [0] Control (default)
■ [1] Management
■ [2] Management Service
For more information on the different optional LDAP services,
see LDAP-based Management and SIP Services on
page223.
Note: Only one LDAP Server Group can be defined for
management.
- 227 -
