User's Manual 160 Document #: LTRT-50614

MP-20x Multimedia Home Gateway

12.3.5 PPTP Tab

The PPTP tab displays the PPTP settings.

Note: This tab is applicable only to PPTP connections.

Figure 12-39: Editing Connection - PPTP Tab

Table 12-4: PPTP Tab Parameter Descriptions

Parameter Description

PPTP Server Host

Name or IP Address

PPTP server host name or IP address provided by your ISP.

Default Chapter3
