AudioCodes MP-20 Series User Manual

User's Manual 4. Device Quick Setup
Version 4.4.3 33 MP-20x Multimedia Home Gateway
4 Device Quick Setup
The procedure below describes how to quickly configure your device for connecting it to
the Internet (WAN).
4.1 Preparing Initial Configuration
The procedure below describes how to prepare the initial configuration.
 To initially prepare for configuration:
1. Connect the cables as shown in Section 2 on page 19.
2. Power on the device.
3. From your browser, enter the device's default IP address (192.168.2.1).
4. From the ‘Language’ drop-down list, select the desired language for the Web graphical
user interface (GUI) display.
5. In the 'User Name' and 'Password' fields, define a login username and password,
respectively and then click Continue.
Figure 4-1: Login Screen
Table 4-1: Login Parameters Description
Parameter Description
User Name
Defines the username.
The valid value is a string of up to 64 lower case characters.
Note: The Web interface accepts upper case letters, but saves them
in lower case.
Password
Defines the user's password.
The valid value is a string of up to 64 characters. The Web interface
accepts all characters.
