User's Manual 20 Document #: LTRT-50614
MP-20x Multimedia Home Gateway
MP-20x provides LEDs on the front panel for indicating various operating status, as described in the
table below:
Table 2-1: MP-204B LEDs Description
LED Color State Description
POWER
Green
On Power received by MP-20x
- Off MP-20x has been powered off
STATUS
Green
On System start-up successful
Red
On Reboot (automatic, by default)
PHONE
1- 4
Green
Type 1 Blinking Idle Proxy register ok
On Off-hook
Type 2 Blinking Phone ringing
Type 3 Blinking Upgrade in process (all LEDs including STATUS LED)
Red
On Idle Proxy register failed
- Off On-hook and not ringing, not using Proxy
LAN /
WAN
Yellow
Steady On Connected at 10 Mbps
Steady On Connected at 100 Mbps
Blinking Activity - there is traffic on 10/100 Mbps
Green
Steady On Connected at 1000 Mbps
Blinking Activity - there is traffic on 1000 Mbps
- Off Disconnected
USB
Green
On USB device is connected
- Off No USB device is connected
