AudioCodes MP-20 Series User Manual

User's Manual 12. Network Connections
Version 4.4.3 169 MP-20x Multimedia Home Gateway
Parameter Description
Multicast
IGMP Proxy Internal IGMP proxy enables the system to issue IGMP host
messages on behalf of hosts that the system discovered through standard
IGMP interfaces. IGMP proxy enables the routing of multicast packets
according to the IGMP requests
of LAN devices asking to join multicast groups.
Select the 'Multicast IGMP Proxy Internal' check-box to enable this feature.
Routing Table Allows you to add or modify routes when this device is active. Use the New
Route button to add a route or edit existing routes.
12.4.3 Advanced Tab
Your Telephone Adapter’s firewall helps protect your computer by preventing unauthorized
users from gaining access to it through a network such as the Internet. The firewall can be
activated per network connection. To enable the firewall on this network connection, select
the 'Enabled' check box. For detailed information on your device's security features, see
Section 5.
Figure 12-51: Internet Connection Firewall
You can add alias names (additional IP addresses) to the device by clicking the 'New IP
Address' link. This enables you to access the device using these aliases in addition to the
IP address (e.g., 192.168.2.1) and http://mp202.home.
