5.2 Menu Bar Description
The Web interface screens are conveniently grouped into related themes under specific
menus. These menus are located in the menu bar. The table below describes these
menus.
Table 5-1: Menu Description
Menu Description
Home Displays the Map View (refer to Chapter 6 on page 61).
Quick Setup
Displays the 'Quick Setup' screen for quickly
setting up an Internet connection with
the device (see Section 8.1 on page 65).
Network
Connections
Displays the 'Network Connections' screen for configuring network connections:
 LAN (see Section 12.2 on page 147)
 WAN (see Chapter 12 on page 133)
 VLANs (see Section 12.4 on page 162)
 LAN-WAN bridging (see Section 12.5 on page 170)
Security
Displays the 'Security' screen for configuring security-related features such as
Website restrictions (see Chapter 15 on page 237).
Voice Over IP
Displays the 'Voice Over IP' screen for configuring the VoIP parameters to use
the
device's VoIP functionality to place and receive calls over the Internet using a
standard telephone set.
QoS
Displays the 'Quality Of Service' screen for configuring Quality of Service (QoS)
for the device (see Chapter 11 on page 115).
Advanced
Displays the 'Advanced' screen for configuring system parameters (e.g., DHCP
server and DNS) and for administrative functions (e.g.,
changing password, setting
date and time, and upgrading the system).
Icon Name Description
3G USB
Displays 3G dongle status and 3G dongle
access codes (see Section 3.2.3 page 29).
About MP20x
Displays technical information about the
device, including version number (see
Section 20.2 on page 301).
Certificates
Manages digital certificates (see
Section 14.3 on page 209).
Configuration
File
Loads the Configuration File to the device
(see Section 20.4 on page 305).
Note: You can hide the Configuration File
icon, by running the following CLI
command in a Telnet session with the
device:
conf_set
rmt_config/hide_config_file_page
1. This is useful, for example, in scenarios
where you want to prevent a user
accessing the Web interface to change the
