User's Manual 54 Document #: LTRT-50614

MP-20x Multimedia Home Gateway

5.5 Set Commands

This section describes the Set commands used for viewing and changing the user’s

permissions. The example below shows how to enable the 'Advanced' menu page and

then to enable the Reboot option under the 'Advanced' page.

conf> set_permission admin/role/6/permission page_advanced 1

Returned 0

conf> reconf 1

Returned 0

conf> set_permission admin/role/6/permission reboot 1

Returned 0

conf> reconf 1

Returned 0

conf>

Note: In some cases, you need to enable specific pages prior to others. For

example enabling “reboot” will not be displayed, before “page_advanced” is enabled.
