Chapter 4: AC Drive Parameters
Page 4–33
DURApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
duraPulse GS4 Parameter DetailS
exPlanation oF ParaMeter details ForMat
Type Hex Addr Dec Addr
Px.xx Descriptive Parameter Name
♦R/W xxxx 4xxxx
Range/Units Default
xx~xxx�xx
xx
Where:
•
Px�xx = Parameter number, followed by descriptive parameter name
•
Type = Parameter type (♦R/W)
♦ = Parameter can be set while drive is in run mode
R/W = Read/Write parameter
Read = Read-only; parameter can be read from, but not written to
•
Hex Addr = Hexadecimal parameter address
•
Dec Addr = Modbus decimal parameter address
•
Range/Units = Range of parameter settings, including units if applicable
•
Default = Parameter default setting
(Parameters can be restored to their default values using P9.08.)
grouP P0.xx details – Motor ParaMeters
Type Hex Addr Dec Addr
P0.00 Motor 1 Maximum Output Voltage
R/W 0000 40001
Range/Units (Format: 16-bit unsigned) Default
230V: 0�0~255�0V
460V: 0�0~510�0V
GS4-2xxx: 230�00
GS4-4xxx: 460�00
This parameter determines the Maximum Output Voltage of the GS4 drive. The Maximum Output
Voltage setting must be less than or equal to the rated voltage of the motor as indicated on the
motor nameplate.
Type Hex Addr Dec Addr
P0.01 Motor 1 Rated Current
R/W 0001 40002
Range/Units (Format: 16-bit unsigned) Default
10~120% drive rated Amps
90% rated current of GS4
Set the value of this parameter according to the full load amperage rating (FLA) of the motor as
indicated on the motor nameplate. The Default setting is 90% of the GS4 drive (Variable Torque)
rated current. Motor 1 Rated Current is used in the GS4 drive as the threshold for motor overload
calculations, when Motor 1 is the selected motor.
Example:
•
The rated output current for the GS4-47P5 drive is 12A� The default setting will be 10�8A, which is
90% of the GS4 drive VT current rating�
•
The range of the parameter is 10% to 120% of the GS4 VT current rating�
(12 x 10% = 1�2A and 12 x 120% = 14�4A)�
