Automation Direct DURApulse GS4 User Manual

Appendix A: Accessories
Page A–25
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
COnDUit bOx kit
Optional conduit box kits can be ordered separately. The kits bolt onto the bottom of the
applicable GS4 drive to provide a convenient connection point for conduit entry.
Note: Frames A through C have integral conduit box space built into the drive. No separate conduit
box is available.
Frame D Frame D0 Frame E
Applicable models Applicable models Applicable models
GS4-2040; GS4-2050;
GS4-4075; GS4-4100
GS4-4060, GS4-4050
GS4-2060; GS4-2075; GS4-2100;
GS4-4125; GS4-4150
Model GS4-CBX-D Model GS4-CBX-D0 Model GS4-CBX-E
ITEM Description Qty. ITEM Description Qty. ITEM Description Qty.
1 Screw M5x0�8x10L 4 1 Screw M5x0�8x10L 4 1 Screw M5x0�8x10L 6
2 Bushing Rubber 28 2 2 Bushing Rubber 28 2 2 Bushing Rubber 28 2
3 Bushing Rubber 44 2 3 Bushing Rubber 44 2 3 Bushing Rubber 44 4
4 Bushing Rubber 88 2 4 Bushing Rubber 73 2 4 Bushing Rubber 100 2
5 Conduit box cover 1 5 Conduit box cover 1 5 Conduit box cover 1
6 Conduit box base 1 6 Conduit box base 1 6 Conduit box base 1
ITEM 1
ITEM 6
ITEM
1
ITEM 1
ITEM 1
ITEM 5
ITEM
2
ITEM 4
ITEM 4
ITEM 3
ITEM 3
ITEM 2
ITEM 1
ITEM 1
ITEM 1
ITEM 1
ITEM 5
ITEM
6
ITEM
4
ITEM 2
ITEM 2
ITEM 3
ITEM 3
ITEM 4
ITEM 6
ITEM
7
ITEM 1
ITEM 2
ITEM
5
ITEM 4
ITEM 5
ITEM 2
ITEM 3
ITEM 3
Frame F Frame G
Applicable models Applicable models
GS4-4150; GS4-4200 GS4-4250; GS4-4300
Model GS4-CBX-F Model GS4-CBX-G
ITEM Description Qty. ITEM Description Qty.
1 Screw M5x0�8x10L 8 1 Screw M5x0�8x 10L 10
2 Bushing Rubber 28 2 1 Screw M8x1�25x10L 4
3 Bushing Rubber 44 4 2 Bushing Rubber 28 2
4 Bushing Rubber 100 2 3 Bushing Rubber 44 2
5 Conduit box cover 1 4 Bushing Rubber 130 3
6 Conduit box base 1 5 Conduit box base 1
6 Conduit box cover 1
ITEM 1
ITEM 1
ITEM 1
ITEM 1
ITEM 1
ITEM 5
ITEM 3
ITEM 3
ITEM 6
ITEM 2
ITEM 3
ITEM 2
ITEM 3
ITEM 4
ITEM 4
ITEM 1
ITEM 5
ITEM 6
ITEM 2
ITEM 3
ITEM 4
ITEM 3
ITEM 4
ITEM 2
ITEM 4
