fUses
Protection devices are essential to prevent damage to your GS4 drive and application equipment.
Please use the fuse specification chart below to select fuses that are applicable to your GS4 drive.
Only use UL-certified fuses which comply with your local regulations.
Fuse Specification Chart GS4 DURApUlse Drives
Drive Model
For Three-Phase Input Power For Single-Phase Input Power
HP
Input Power Input Fuse
HP
Input Power Input Fuse
Ø Volts
GS4
Amps
Fuse
Amps
Fast
Acting
Class T
Edison
Class J* Ø Volts
GS4
Amps
Fuse
Amps
Fast
Acting
Class T
Edison
Class J*
GS4-21P0
1 3 230 6�4 10 TJN10 JHL10 0�5 1 230 6�4 10 TJN10 JHL10
GS4-22P0
2 3 230 12 15 TJN15 JHL15 0�75 1 230 9�7 15 TJN15 JHL15
GS4-23P0
3 3 230 16 25 TJN25 JHL25 1 1 230 15 20 TJN20 JHL20
GS4-25P0
5 3 230 20 35 TJN35 JHL35 2 1 230 20 30 TJN30 JHL30
GS4-27P5
7�5 3 230 28 50 TJN50 JHL50 3 1 230 26 40 TJN40 JHL40
GS4-2010
10 3 230 36 70 TJN70 JHL70 3 1 230 26 40 TJN40 JHL40
GS4-2015
15 3 230 52 100 TJN100 JHL100 5 1 230 40 70 TJN70 JHL70
GS4-2020
20 3 230 72 125 TJN125 JHL125 7�5 1 230 58 100 TJN100 JHL100
GS4-2025
25 3 230 83 150 TJN150 JHL150 10 1 230 76 125 TJN125 JHL125
GS4-2030
30 3 230 99 175 TJN175 JHL175 10 1 230 76 125 TJN125 JHL125
GS4-2040**
40 3 230 124 175 TJN175 JHL175 10 1 230 63 90 TJN90 JHL90
GS4-2050**
50 3 230 143 200 TJN200 JHL200 10 1 230 63 90 TJN90 JHL90
GS4-2060
60 3 230 171 250 TJN250 JHL250 15 1 230 94 150 TJN150 JHL150
GS4-2075
75 3 230 206 300 TJN300 JHL300 20 1 230 124 175 TJN175 JHL175
GS4-2100
100 3 230 245 350 TJN350 JHL350 25 1 230 143 200 TJN200 JHL200
GS4-41P0
1 3 460 4�3 6 TJS6 JHL6
n/a
GS4-42P0
2 3 460 5�9 10 TJS10 JHL10
GS4-43P0
3 3 460 8�7 15 TJS15 JHL15
GS4-45P0
5 3 460 14 20 TJS20 JHL20
GS4-47P5
7�5 3 460 17 25 TJS25 JHL25
GS4-4010
10 3 460 20 35 TJS35 JHL35
GS4-4015
15 3 460 26 45 TJS45 JHL45
GS4-4020
20 3 460 35 60 TJS60 JHL60
GS4-4025
25 3 460 40 70 TJS70 JHL70
GS4-4030
30 3 460 47 90 TJS90 JHL90
GS4-4040**
40 3 460 63 125 TJS125 JHL125
GS4-4050
50 3 460 74 100 TJS100 JHL100
GS4-4060
60 3 460 101 125 TJS125 JHL125
GS4-4075
75 3 460 114 150 TJS150 JHL150
GS4-4100
100 3 460 157 200 TJS200 JHL200
GS4-4125
125 3 460 167 250 TJS250 JHL250
GS4-4150
150 3 460 207 300 TJS300 JHL300
GS4-4175
175 3 460 240 350 TJS350 JHL350
GS4-4200
200 3 460 300 450 TJS450 JHL450
GS4-4250
250 3 460 380 500 TJS500 JHL500
–
–
Fast Acting
Current Limiting
Class L
GS4-4300
300 3 460 400 700 LCU700
* High-speed Class J
** Includes DC choke
