Automation Direct DURApulse GS4 User Manual

Page A–12
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Appendix A: Accessories
dC reaCTors (Choke) speCifiCaTion CharTs
Supply: 230V, 1Ø, 50/60 Hz DC Reactors*
GS4 Model HP
Nominal
Amps (rms)
Saturation
Amps (rms)
Inductance (mH)
3%
Impedance
5%
Impedance
GS4-21P0 0�5 4�2 7�5 5�284 8�806
GS4-22P0 0�75 5�6 10�0 3�963 6�604
GS4-23P0 1 8�7 15�6 2�536 4�227
GS4-25P0 2 14 25 1�585 2�642
GS4-27P5 3 19 34 1�153 1�921
GS4-2010 3 19 34 1�153 1�921
GS4-2015 5 30 53 0�746 1�243
GS4-2020 7�5 43 78 0�507 0�845
GS4-2025 10 57 103 0�384 0�640
GS4-2030 10 57 103 0�384 0�640
GS4-2040 10 N/A N/A N/A N/A
GS4-2050 10 N/A N/A N/A N/A
GS4-2060 15 N/A N/A N/A N/A
GS4-2075 20 N/A N/A N/A N/A
GS4-2100 25 N/A N/A N/A N/A
* Drive output HP is derated when supplied with single-phase input
Supply: 230V, 3Ø, 50/60 Hz DC Reactors
GS4 Model HP
Nominal
Amps
(rms)
Saturation
Amps
(rms)
Inductance (mH)
3%
Impedance
5%
Impedance
GS4-21P0 1 5�8 8�6 4�392 7�607
GS4-22P0 2 9�2 12�8 2�745 4�754
GS4-23P0 3 13 18 1�996 3�457
GS4-25P0 5 20 29 1�293 2�239
GS4-27P5 7�5 29 43 0�878 1�521
GS4-2010 10 38 56 0�637 1�104
GS4-2015 15 57 85 0�430 0�745
GS4-2020 20 75 112 0�325 0�562
GS4-2025 25 87 128 0�293 0�507
GS4-2030 30 104 155 0�245 0�424
GS4-2040 40 N/A N/A N/A N/A
GS4-2050 50 N/A N/A N/A N/A
GS4-2060 60 N/A N/A N/A N/A
GS4-2075 75 N/A N/A N/A N/A
GS4-2100 100 N/A N/A N/A N/A
Supply: 460V, 3Ø, 50/60 Hz DC Reactors
GS4 Model HP
Nominal
Amps
(rms)
Saturation
Amps
(rms)
Inductance (mH)
3%
Impedance
5%
Impedance
GS4-41P0 1 3�5 5�2 14�032 23�387
GS4-42P0 2 4�6 6�8 10�525 17�541
GS4-43P0 3 6�9 10�3 7�015 11�692
GS4-45P0 5 10�4 14�6 4�677 7�795
GS4-47P5 7�5 14 20 3�508 5�846
GS4-4010 10 21 31 2�338 3�897
GS4-4015 15 28 41 1�755 2�925
GS4-4020 20 37 54 1�315 2�191
GS4-4025 25 44 65 1�107 1�846
GS4-4030 30 52 77 0�936 1�560
GS4-4040 40 73 103 0�701 1�169
GS4-4050 50 N/A N/A N/A N/A
GS4-4060 60 N/A N/A N/A N/A
GS4-4075 75 N/A N/A N/A N/A
GS4-4100 100 N/A N/A N/A N/A
GS4-4125 125 N/A N/A N/A N/A
GS4-4150 150 N/A N/A N/A N/A
GS4-4175 175 N/A N/A N/A N/A
GS4-4200 215 N/A N/A N/A N/A
GS4-4250 250 N/A N/A N/A N/A
GS4-4300 300 N/A N/A N/A N/A
