Page 3–10
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 3: Keypad Operation and Quick-Start
Keypad Lock - Keypad Lock Page
Keypad Lock
Press ENTER to
Lock Key
Keypad Lock is used to lock the keypad from unintentional
activation during operation.
Press the Enter key to lock the keypad.
LOCAL
▲
F 60.00 Hz
▼
H 0.00 Hz
v 335.6 Vdc
JOG 03:45:36
The Status Page will again display.
Keypad Lock
Press ESC 3sec
to UnLock Key
Pressing ANY key will display the message Press ESC to UnLock Key.
LOCAL
▲
F 60.00 Hz
▼
H 0.00 Hz
v 335.6 Vdc
JOG 03:46:12
Press and hold the ESC key for 3 seconds to unlock the keypad. The
display will return to the Status Page.
