Page B–8
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Appendix B: Optional I/O and Communication Cards
OPtiOnal COMMUniCatiOns CarDs
The following chart lists the optional communication cards available for GS4 series drives.
GS4 Optional Communication Cards *
Part Number Description Placement
GS4-CM-MODTCP *
DURApulse communication card, Modbus TCP,
10/100 Mbps auto-detect, Ethernet (RJ45) port�
For use with GS4 series AC drives�
Slot 1Slot 2
(factory-installed card)
Slot 3
GS4-CM-ENETIP *
DURApulse communication card, EtherNet/IP
10/100 Mbps auto-detect, Ethernet (RJ45) port�
For use with GS4 series AC drives�
* Communication cards can be installed only in Slot #1 of the GS4 drive, and only one comm
card at a time can be installed.
