Appendix A: Accessories
eMi inPUt filters
The optional accessories listed in this chapter are available for use with the GS4 drive. Selection
of these accessories is application specific and may improve drive performance. Additional
information regarding filter installation and operation is available in the AutomationDirect white
paper, "Applied EMI/RFI Techniques Overview."
EMI Filters Selection
Model* Description EMI Filter
Max Power
kW [max/ph]
Max Torque
kg·cm [lb·in]
SCCR Rating
(kA)
GS4-21P0 230V 3ph 1�0 hp
KMF325A
20�8
[6]
17�7
[2]
5
GS4-22P0 230V 3ph 2�0 hp
GS4-23P0 230V 3ph 3�0 hp
GS4-25P0 230V 3ph 5�0 hp
GS4-27P5 230V 3ph 7�5 hp
KMF370A
58�1
[16�8]
44�2
[5]
5
GS4-2010 230V 3ph 10hp
GS4-2015 230V 3ph 15hp
GS4-4025 460V 3ph 25hp
GS4-4030 460V 3ph 30hp
GS4-4040 460V 3ph 40hp
GS4-2020 230V 3ph 20hp
KMF3100A
83
(24)
44�2
[5]
10GS4-2025 230V 3ph 25hp
GS4-2030 230V 3ph 30hp
GS4-41P0 460V 3ph 1�0 hp
KMF318A
14�9
[4�3]
17�7
[2]
5
GS4-42P0 460V 3ph 2�0 hp
GS4-43P0 460V 3ph 3�0 hp
GS4-45P0 460V 3ph 5�0 hp
GS4-47P5 460V 3ph 7�5 hp
GS4-4010 460V 3ph 10hp
KMF350A
41�5
[12]
44�2
[5]
10GS4-4015 460V 3ph 15hp
GS4-4020 460V 3ph 20hp
GS4-2040 230V 3ph 40hp
MIF3150
124�6
[36]
177
[20]
10
GS4-2050 230V 3ph 50hp
GS4-4075 460V 3ph 75hp
GS4-4100 460V 3ph 100hp
GS4-2060 230V 3ph 60hp
MIF3400B
332�2
[96]
265�5
[30]
30
GS4-2075 230V 3ph 75hp
GS4-2100 230V 3ph 100hp
GS4-4125 460V 3ph 125hp
GS4-4150 460V 3ph 150hp
GS4-4175 460V 3ph 175hp
GS4-4200 460V 3ph 200hp
GS4-4250 460V 3ph 250hp
MIF3800 &
Qty. 3
TOR254
664�3
[192]
265�5
[30]
30
GS4-4300 460V 3ph 300hp
* EMI filter selections for GS4-2xxx models are the same whether that particular model
is supplied 1-Phase or 3-Phase 230VAC.
