Automation Direct DURApulse GS4 User Manual

Chapter 5: Serial Communications
Page 5–9
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Common Third-parTy modbus rTu masTers
• KEPSERVER EX 5�0 from www�kepware�com
• Modbus Poll from www�modbustools�com
auTomaTiondireCT plCs as modbus masTer
Serial Modbus-capable AutomationDirect PLCs can communicate with the GS4 drive (for GS4
Ethernet connectivity and control, refer to the Ethernet option card information in Appendix B).
Serial Modbus control is easier to accomplish from a PLC that has a built-in RS-485 port and
supports dedicated Modbus messaging. [RS-232-only PLCs will require an RS-232–RS-485
converter (FA-ISOCON); and older PLCs may require programming to construct the Modbus
strings.] We recommend PLCs with built-in RS-485 ports and dedicated Modbus serial commands:
CLICK (with RS-485 ports), P2000, P3000, BRX/Do-more, DirectLogic (DL06 or D2-260). Other
PLC-Drive connectivity is possible: Please refer to the “Typical ADC PLC to GS4 Serial Connectivity
Matrix” below.
Typical ADC PLC to GS4 Serial Communications Connectivity
Typical ADC PLC to GS4 Serial Communications Connectivity Matrix*
Recommended PLC Connectivity
Communication Direct Cable
GS4
PLC Port # Port Type
Port
Type
Port #
CLICK
3 3 screw terminals RS-485 L19954 cable
RJ45
or
SG+
SG-
SGND
RJ45-1
RJ45-2
or
3 screw
terminals
D2-260
2 HD15 RS-485 D2-DSCBL-2
DL06
2 HD15 RS-485 D2-DSCBL-2
BRX/Do-more
RS-485 3 screw terminals RS-485 L19954 cable
Do-more H2-DM1
RS-232 RJ12
RS-232 to
RS-485
FA-ISOCON
with L19954
cable
P2-550
RS-485 3 screw terminals RS-485 L19954 cable
P3-530
RS-485 3 screw terminals RS-485 L19954 cable
P3-550
RS-485 3 screw terminals RS-485 L19954 cable
P3-550E
RS-485 3 screw terminals RS-485 L19954 cable
Other PLC Connectivity
– –
D2-250-1
2 HD15 RS-485 D2-DSCBL-2
D4-450/D4-454
1 DB25
RS-232 to
RS-485
FA-ISOCON
with L19954
cable
DL05
2 RJ12
RS-232 to
RS-485
FA-ISOCON
with L19954
cable
DL06 + DCM
2 HD15 RS-485 D2-DSCBL-2
Do-more H2-DM1 + H2-SERIO-4
3 5 screw terminals RS-485 L19954 cable
Do-more T1H-DM1
RS-232 RJ12
RS-232 to
RS-485
FA-ISOCON
with L19954
cable
P2-SCM
4 4 screw terminals RS-485 L19954 cable
P3-SCM
4 4 screw terminals RS-485 L19954 cable
* Ethernet connectivity for EtherNet/IP communication is possible with an optional communication
card # GS4-CM-ENETIP. Refer to “Appendix B: Optional I/O and Communication Cards” for details.
* Ethernet connectivity for Modbus TCP communication is possible with an optional communication
card # GS4-CM-MODTCP. Refer to “Appendix B: Optional I/O and Communication Cards” for details.
