Page 3–6
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 3: Keypad Operation and Quick-Start
QUiCk-start – QUiCk-start Page
The Quick Start function allows the user to set typically used parameters for quick drive startup
and motor protection.
For basic applications, it may only be necessary to enter parameters into the “Basic Configuration”
Menu. The “Basic” menu contains Motor definition/protection information and a bare minimum
set of parameters that will need to be set. “Control I/O” allows for customization of the most
common I/O settings, and each subsequent menu configures additional features and allows more
customization of the drive.
If the GS4 drive has been previously configured, it is advisable to restore the default settings (by
using parameter P9.08) before reconfiguring the drive.
Quick Start
▲
1:Basic Config
▼
2:Control I/O
3:Enhancements
The Quick Start function allows the user to quickly set typically used
parameters. Not all of the six Quick Start categories need to be
configured for every application, but the categories that are needed
for the particular application should be configured in sequential
order as shown below (starting with 1:Basic Config).
1: Basic Config
2: Control I/O
3: Enhancements
4: Protection
5: PID
6: My Menu (User Defined Quick Start Menu)
1: basiC Config
Basic Con :P00.00
▲
01:Mtr1 Max VoltOut
▼
02:Mtr1 Amps Rated
03:Mtr1 Base Hz
Parameters in the Basic Configuration menu:
1 P0.00 Motor 1 Maximum Output Voltage
2 P0.01 Motor 1 Rated Current
3 P0.02 Motor 1 Base Frequency
4 P0.03 Motor 1 Rated RPM
5 P0.04 Drive Maximum Output Frequency
6 P0.08 Motor 1 Rated Horsepower (HP)
7 P0.09 Motor 1 Number of Poles
8 P1.00 Stop Method
9 P1.01 Acceleration Time 1
10 P1.02 Deceleration Time 1
11 P3.00 1st Source of Operation Command [Remote]
12 P3.01 2nd Source of Operation Command [Local]
13 P4.00 1st Source of Frequency Command [Remote]
14 P4.01 2nd Source of Frequency Command [Local]
15 P6.00 Electronic Thermal Overload Relay (Motor 1)
16 P6.01 Electronic Thermal Characteristic (Motor 1)
17 P6.33 Drive Derating Method
18 P6.34 Variable/Constant Torque Duty Selection
19 P9.08 Restore to Default
