Automation Direct DURApulse GS4 User Manual

Chapter 3: Keypad Operation and Quick-Start
Page 3–7
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
2: ConTrol i/o
Control I :P03.02
▲
01:2,3 wire Control
▼
02:DI1 Function
03: DI2 Function
Parameters in the Control I/O menu:
1 P3.02 2/3 Wire Operation Mode
2 P3.03 Multi-Function Input (DI1)
3 P3.04 Multi-Function Input (DI2)
4 P3.05 Multi-Function Input (DI3)
5 P3.06 Multi-Function Input (DI4)
6 P3.17 Multi-Function Output Terminal 1 (Relay 1)
7 P3.18 Multi-Function Output Terminal 2 (Relay 2)
8 P4.02 Analog Input 1 (AI1) Function
9 P4.03 Analog Input 2 (AI2) Function
10 P4.05 AI1 – I/V Selection
11 P4.06 AI2 – I/V Selection
12 P4.09 Analog Frequency Command for Reverse Run
13 P4.10 AI1 Input Bias (Offset)
14 P4.11 AI1 Input Bias (Offset) Polarity
15 P4.12 AI1 Input Gain
16 P4.13 AI1 Filter
17 P4.15 AI2 Input Bias (Offset)
18 P4.16 AI2 Input Bias (Offset) Polarity
19 P4.17 AI2 Input Gain
20 P4.18 AI2 Filter
21 P4.50 Analog Output 1 (AO1)
22 P4.51 AO1 Gain
23 P4.52 AO1 Negative Value Handle
24 P4.53 AO1 0~20mA/4~20mA Selection
25 P4.60 AO1 Output Constant Level
26 P5.01 Multi-Speed 1
27 P5.02 Multi-Speed 2
28 P5.03 Multi-Speed 3
29 P5.04 Multi-Speed 4
3: enhanCemenTs
Enhanceme :P01.09
▲
01:S Curve Acc1
▼
02:S Curve Dec1
03:Jog Acc Time
Parameters in the Enhancements menu:
1 P1.09 S-curve Accel Time 1
2 P1.10 S-curve Decel Time 1
3 P1.13 Jog Acceleration Time
4 P1.14 Jog Deceleration Time
5 P5.00 Jog Frequency
6 P1.19 Skip Frequency 1 Upper Limit
7 P1.20 Skip Frequency 1 Lower Limit
8 P1.25 DC Injection Current Level
9 P1.26 DC Injection Time During Start-up
10 P1.27 DC Injection Time During Stopping
11 P1.28 Start-Point for DC Injection During Stopping
12 P2.00 Volts/Hertz Settings
13 P2.01 Slip Compensation Gain
14 P2.25 Slip Compensation Filter
15 P2.02 Torque Compensation Gain
16 P2.03 Torque Compensation Filter
17 P2.10 PWM Carrier Frequency
18 P2.11 Control Mode
19 P2.18 Zero Speed Select
20 P6.25 Upper Limit of Output Frequency
21 P2.23 Automatic Energy-Saving Operation
22 P2.24 Power Saving Gain
23 P2.26 Slip Deviation Level
24 P2.27 Slip Deviation Detection time
25 P2.28 Slip Deviation Treatment
