Page 3–8
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Chapter 3: Keypad Operation and Quick-Start
4: proTeCTion
Protectio :P06.04
▲
01:Auto Restart Qty
▼
02:Reset Window
03:BB Spd Searc
Parameters in the Protection menu:
1 P6.04 Auto Restart after Fault
2 P6.05 Reset Time for Auto Restart after fault
3 P6.06 Base Block Speed Search after Fault (oc,ov,bb)
4 P6.09 Fwd/Rev Direction Inhibit
5 P6.13 Auto Adjustable Accel/Decel
6 P6.14 Over-torque Detection Mode (OT1)
7 P6.15 Over-torque Detection Level (OT1)
8 P6.16 Over-torque Detection Time (OT1)
9 P6.26 Lower Limit of Output Frequency
10 P6.28 Dynamic Braking Voltage Level
11 P6.29 Line Start Lockout
12 P6.31 Cooling Fan Control
13 P6.32 PWM Fan Speed
14 P6.45 Output Phase Loss (OPhL) Detection Selection
15 P6.46 Output Phase Loss Detection time
16 P6.47 Output Phase Loss Current Detection Level
17 P6.49 Input Phase Loss Treatment
18 P6.69 Input Phase Loss Detection Time
19 P6.70 Input Phase Loss Ripple Detection
20 P6.50 GFF Detect Current Level (% of INV I-Rated)
21 P6.51 GFF Low Pass Filter Gain
22 P6.71 STO Alarm Latch
5: pid
PID :P7.00
▲
01:PID Fbk Select
▼
02:Rem Freq Src
03:Loc Freq Src
Parameters in the PID menu:
1 P7.00 PID Action/Mode
2 P4.00 1st Source of Frequency Command [Remote]
3 P4.01 2nd Source of Frequency Command [Local]
4 P4.02 Analog Input 1 (AI1) Function
5 P4.03 Analog Input 2 (AI2) Function
6 P4.04 Analog Input 3 (AI3) Function
7 P4.05 AI1 – I/V Selection
8 P4.06 AI2 – I/V Selection
10 P7.03 PID Feedback Gain
11 P7.04 PID Offset Value
12 P7.13 Proportional Gain
13 P7.14 Integral Time
14 P7.15 Derivative Value
15 P7.18 PID Output Frequency Limit
16 P7.20 Feedback Signal Detection Time
17 P7.21 PID Feedback Loss
18 P7.22 PID Feedback Loss Speed Level Default
19 P7.25 PID Mode Selection
20 P7.26 PID Reverse Enable
21 P8.00 User Display
22 P8.01 Start-up Display Selection
23 P8.02 User Defined Format
24 P8.03 User Defined Max
25 P8.04 User Defined Setpoint
