Automation Direct DURApulse GS4 User Manual

Chapter 3: Keypad Operation and Quick-Start
Page 3–5
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
MenU Page
Menu
▲
1:Param Setup
▼
2:Quick Start
3:Keypad Lock
Press the Menu button from any page to access the Menu Page. Use
the Up and Down Direction keys to scroll through the Menu content.
Press the Enter key to open the selected Menu content item.
1: Param Setup - Parameter Setup
Set up the individual drive parameters.
2: Quick Start
Set typically used parameters to allow quick drive startup.
3: Keypad Lock
Lock the Keypad.
4: Fault Record
Display fault information for the drive.
5: PLC
Run the current PLC program.
6: Copy Param - Copy Parameters
Save drive parameters to the keypad or drive.
7: Copy PLC
Copy a previously saved PLC program to the keypad or drive.
8: Displ Setup
Adjust contrast and backlight settings for the display.
9: Time Setup
Set the time.
10: Language
Set the display language.
11: Start-up
Set the Start-up Page display.
Param Setup - Parameter Setup Page
Param Setup
▲
00:MOTOR
▼
01:RAMPS
02:V-Hz
See the individual parameter summary tables in Chapter 4 - AC Drive
Parameters for specific parameter explanations and settings.
00: MOTOR
01: RAMPS
02: V-Hz
03: DIGITAL
04: ANALOG
05: PRESETS
06: PROTECT
07: PID
08: DISPLAY
09: COMMUNICATION
10: PUMP
11: FAULTS
