Appendix A: Accessories
Page A–11
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
line/load reaCTors seleCTion CharTs (ConTinued)
Supply: 230V, 3Ø, 50/60 Hz (Variable Torque; reactor installed Line or Load Side)
GS4 Model hp
VT: 3Ø
Output
Amps
(rms)
Saturation
Amps
(rms)
Inductance (mH)
Max Motor
kW
LR Model*
Rated
Amps
LR 3%
Inductance
3%
Impedance
5%
Impedance
GS4-21P0 1 5 8�7 2�536 4�226 0�75 LR-21P0 4�6 2�46
GS4-22P0 2 8 12�8 1�585 2�641 1�5 LR-23P0* 10�6 0 �97
GS4-23P0 3 11 18 1�152 1�921 2�2 LR-23P0 10�6 0�97
GS4-25P0 5 17 29 0�746 1�244 3�7 LR-25P0 16�7 0�626
GS4-27P5 7�5 25 43 0�507 0�845 5�5 LR-27P5 24�2 0�434
GS4-2010 10 33 56 0�320 0�534 7�5 LR-2010 30�8 0�342
GS4-2015 15 49 85 0�216 0�359 11 LR-2015 46�2 0�22
GS4-2020 20 65 112 0�163 0�271 15 LR-2020 59�4 0�172
GS4-2025 25 75 128 0�169 0�282 18�5 LR-2025 74�8 0�138
GS4-2030 30 90 155 0�141 0�236 22 LR-2040* 114 0�0886
GS4-2040 40 120 205 0�106 0�176 30 LR-2040 114 0�0886
GS4-2050 50 146 250 0�087 0�146 37 LR-2050 143 0�0699
GS4-2060 60 180 308 0�070 0�117 45
not
available*
169 0�0624
GS4-2075 75 215 367 0�059 0�098 55 211 0�0487
GS4-2100 100 255 436 0�049 0�082 75 273 0�0364
* Some GS4 drive and reactor combinations do not fit the typical "pattern" of having similar part numbers,
due to some GS4 models having higher outputs than previous GS DURApulse drives.
Supply: 460V, 3Ø, 50/60 Hz (Variable Torque; reactor installed Line or Load Side)
GS4 Model hp
VT: 3Ø
Output
Amps
(rms)
Saturation
Amps
(rms)
Inductance (mH)
Max
Motor
kW
LR Model
Rated
Amps
LR 3%
Inductance
3%
Impedance
5%
Impedance
GS4-41P0 1 3 5�2 8�102 13�503 0�75 LR-41P0 2�1 8�927
GS4-42P0 2 4 6�8 6�077 10�128 1�5 LR-42P0 3�4 5�790
GS4-43P0 3 6 10�3 4�050 6�751 2�2 LR-43P0 4�8 4�270
GS4-45P0 5 9 14�6 2�700 4�500 3�7 LR-45P0 7�6 2�770
GS4-47P5 7�5 12 20 2�025 3�375 5�5 LR-47P5 11 1�680
GS4-4010 10 18 31 1�174 1�957 7�5 LR-4010 14 1�290
GS4-4015 15 24 41 0�881 1�468 11 LR-4015 21 0�912
GS4-4020 20 32 54 0�660 1�101 15 LR-4020 27 0�694
GS4-4025 25 38 65 0�639 1�066 18�5 LR-4025 34 0�569
GS4-4030 30 45 77 0�541 0�901 22 LR-4030 40 0�469
GS4-4040 40 60 103 0�405 0�675 30 LR-4040 52 0�387
GS4-4050 50 73 124 0�334 0�556 37 LR-4050 65 0�295
GS4-4060 60 91 155 0�267 0�445 45 LR-4060 77 0�227
GS4-4075 75 110 189 0�221 0�368 55 LR-4075 96 0�196
GS4-4100 100 150 257 0�162 0�270 75 LR-4100 124 0�152
GS4-4125 125 180 308 0�135 0�224 90 LR-4125 156 0�117
GS4-4150 150 220 376 0�110 0�184 110 LR-4150 180 0�103
GS4-4175 175 260 445 0�098 0�163 132 LR-4200 240 0�0839
GS4-4200 215 310 531 0�078 0�130 160 LR-4250 302 0�0654
GS4-4250 250 370 634 0�066 0�109 185 LR-4250 302 0�0654
GS4-4300 300 460 787 0�054 0�090 220 LR-4300 361 0�0565
