Appendix A: Accessories
moTor Cable lengTh CharTs (ConTinued)
GS4 - Supplied 460VAC, Three Phase
GS4 Model kW hp
Without Output AC Reactor With 3% Output AC Reactor
Shielded Cable
ft [m]
Unshielded
Cable
ft [m]
Shielded Cable
ft [m]
Unshielded
Cable
ft [m]
GS4-41P0 0�75 1 164 [50] 246 [75] 246 [75] 377 [115]
GS4-42P0 1�5 2 164 [50] 246 [75] 246 [75] 377 [115]
GS4-43P0 2�2 3 164 [50] 246 [75] 246 [75] 377 [115]
GS4-45P0 3�7 5 164 [50] 246 [75] 246 [75] 377 [115]
GS4-47P5 5�5 7�5 164 [50] 246 [75] 246 [75] 377 [115]
GS4-4010 7�5 10 328 [100] 492 [150] 492 [150] 738 [225]
GS4-4015 11 15 328 [100] 492 [150] 492 [150] 738 [225]
GS4-4020 15 20 328 [100] 492 [150] 492 [150] 738 [225]
GS4-4025 18�5 25 328 [100] 492 [150] 492 [150] 738 [225]
GS4-4030 22 30 328 [100] 492 [150] 492 [150] 738 [225]
GS4-4040 30 40 328 [100] 492 [150] 492 [150] 738 [225]
GS4-4050 37 50 328 [100] 492 [150] 492 [150] 738 [225]
GS4-4060 45 60 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4075 55 75 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4100 75 100 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4125 90 125 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4150 110 150 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4175 132 175 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4200 160 215 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4250 185 250 492 [150] 738 [225] 738 [225] 1066 [325]
GS4-4300 220 300 492 [150] 738 [225] 738 [225] 1066 [325]
