Automation Direct DURApulse GS4 User Manual

Chapter 1: Getting Started
Page 1–13
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
460V Class GS4 Specifications (Model-Specific Specifications) (continued)
Model Name: GS4-xxxx 4025 4030 4040 4050 4060 4075 4100
Frame Size C D0 D
Output
Rating
Constant
Torque
(CT)
Max Motor Output
hp
25 30 40 50 60 75 100
kW
18.5 22 30 37 45 55 75
Rated Output Capacity kVA
29 34 45 55 69 84 114
Rated Output Current A
36 43 57 69 86 105 143
Carrier Frequency kHz
2 to 6
Variable
Torque
(VT)
Max Motor Output
hp
25 30 40 50 60 75 100
kW
18.5 22 30 37 45 55 75
Rated Output Capacity kVA
30 36 48 58 73 88 120
Rated Output Current A
38 45 60 73 91 110 150
Carrier Frequency kHz
2 to 10
Input
Rating *
CT
Rated Input Current A
38 45 60 70 96 108 149
VT
40 47 63 74 101 114 157
Rated Voltage/Frequency
3-phase 380~480 VAC (-15% to +10%), 50/60Hz
Operating Voltage Range
323~528 VAC
Frequency Tolerance
47~63 Hz
Short Circuit Withstand (SCCR)
(A, rms symmetrical)
100kA
Weight (kg [lb])
9.8 [21.6] 27.0 [59.5] 38.5 [84.9]
Watt Loss 100% I (W)
507 635 866 993 1147 1413 1742
Cooling Method
fan
Braking Chopper
built in optional
DC Reactor
optional built in
EMI Filter
optional
Model Name: GS4-xxxx 4125 4150 4175 4200 4250 4300
Frame Size E F G
Output
Rating
Constant
Torque
(CT)
Max Motor Output
hp 125 150 175 215 250 300
kW 90 110 132 160 185 220
Rated Output Capacity kVA 136 167 197 235 280 348
Rated Output Current A 171 209 247 295 352 437
Carrier Frequency kHz 2 to 6
Variable
Torque
(VT)
Max Motor Output
hp 125 150 175 215 250 300
kW 90 110 132 160 185 220
Rated Output Capacity kVA 143 175 207 247 295 367
Rated Output Current A 180 220 260 310 370 460
Carrier Frequency kHz 2 to 9
Input
Rating *
CT
Rated Input Current A
159 197 228 285 361 380
VT 167 207 240 300 380 400
Rated Voltage/Frequency 3-phase 380~480 VAC (-15% to +10%), 50/60Hz
Operating Voltage Range
323~528 VAC
Frequency Tolerance 47~63 Hz
Short Circuit Withstand (SCCR)
(A, rms symmetrical)
100kA
Weight (kg [lb]) 64.8 [143] 86.5 [191] 134 [295]
Watt Loss 100% I (W) 2092 2599 3081 3783 4589 5772
Cooling Method fan
Braking Chopper optional
DC Reactor built in
EMI Filter optional
* If 3-phase power source is non-symmetrical, refer to “Circuit Connections – RFI Jumper” in Chapter 2:
Installation and Wiring, page 2–14.
Please refer to “Appendix A: Accessories” for input fusing information.
