Page A–30
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Appendix A: Accessories
Frame G Conduit Box Installation (continued)
Fasten all the screws. Screw torque: 24~26 kg·cm (20.8~22.6 Ib·in).
Place the cover back to the top and fasten the screws (as shown in the figure).
Screw torque: 12~15 kg·cm (10.4~13 Ib·in).
Remove poWeR fRom dRIve pRIoR to INstAllAtIoN ANd/oR RemovAl of AccessoRIes.
