Page C–2
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Appendix C: Digital and Analog I/O Parameter Maps
intrODUCtiOn
This section contains worksheets to help with designing and programming the physical inputs
and outputs of the GS4 (digital, analog, and frequency interfaces). These worksheets provide the
GS4 parameters and addresses associated with each input and output. For detailed parameter
descriptions, please see Chapter 4 “AC Drive Parameters”. For more detailed wiring information,
please see Chapter 2 “Installation and Wiring.
Digital and analog I/O parameter maps begin on the following page.
