Appendix F: PID Control
Page F–21
DuRApulse GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Type Hex Addr Dec Addr
P8.00 User Display
♦ R/W 0800 42049
User Display (P8.00) Function Settings Applicable for PID Control Default
As Seen During Setup As Displayed During Operation
3
10: PID Feedback %
42: PID Reference
43: PID Offset
44: PID Output Hz
b displayed value %
h displayed value %
o displayed value %
b displayed value Hz
Type Hex Addr Dec Addr
P8.01 Start-up Display Selection
♦ R/W 0801 42050
Range/Units (Format: 16-bit binary) Default
0: Freq Setpoint (F)
1: Output Hz (H)
2: User Display (U)
3: Output Amps (A)
0
This parameter determines the start-up display page after power is applied to the drive. The
sequence does not change; the order of appearance is always (F), (H), (U), then (A). Only
three parameters can be displayed on the keypad screen at a time. P8.01 specifies only which
parameter appears on the top row when the drive is powered up. All four parameters can always
be scrolled to using the keypad up and down arrows. User defined choice (U) displays values and
units according to the setting in P8.00.
Example: If P8.00 = 3, the User Display shows DC Bus Voltage.
If P8.01 = 2, the User Display appears in the top row at power up.
LOCAL
▲
v 266.2 Vdc
▼
A 0.00 Amp
F 60.00 Hz
JOG 14:35:36
To Next Page
