Install and Connect SCC1 (Single-Carrier Cabinets)
Task List: Install and Connect Single-Carrier Cabinets (SCC1)
368 SI Installation and Upgrades
June 2004
Figure 108: Cabinet Earthquake Mounting — Rear View
Figure notes
1 Cabinet
2 Nylon Insulating Washer (2 Required)
3 Long Hex Head Bolt (2 Required)
4 Stiffener
5 Cabinet Foot
6 Floor Plugs (Remove)
7 Concrete Floor Anchor
8 Concrete Floor
3
4
5
1
8
2
7
On
Off
On
Off
6
r781851a CJL 030796
